Fewer parts makes assembly simpler and more cost effective
No tools required to insert and extract contacts
Patented Euro-Lock secures contacts in place
One step cable assembly with optional EMI shielding
SLS (Spring Loaded Sockets) for vibrating environments
Pressure Rating:
Approvals:
IP 67 / IP 69 K per EN 60 529 (connected)
Mechanical Data:
Housing Surface:
Nickel Plated Brass, Aluminum
Contacts:
Gold-plated Brass Alloy
Type of Contacts:
Crimp, Dip Solder
Number of Contacts:
3, 8, 10, 15, 18
Amp Rating:
8 - 20 A
Voltage Rating:
160 - 400 V
Cable OD:
.08" - .43" (2 - 11 mm)
Wire Gauge:
28 AWG
Operating Temperature:
- 40°C to 125°C (- 40°F to 257°F)
Accessories for M16 Signal Connectors
Description
Part Number
Assembly
Tool required for Elbow Connector
7.010.900.125 Add to Quote
Plastic
Protective Cap for Connectors with Male
thread
7.000.980.161 Add to Quote
Brass
Protective Cap for connectors Male thread
7.010.900.162 Add to Quote
Brass
Protective Cap for connectors with Male thread, 70mm chain
7.010.9S0.704 Add to Quote
Crimp tool for manual crimping of machined crimp
contacts (Data Only) for M23 & M16, Crimps
Contact Sizes Between - 0.08 mm² to
2.5mm²,
Click Here -
For Crimp Contact Settings
Previously Protech Systems used ITT Canon flange (panel mount) and plug connectors. The connectors are made of light cast iron that when hit even by soft impact, gets damaged. We had repair requests by our customers consistently.
Protech discovered Sealcon connectors in a Nedco Electronics flyer. We contacted Sealcon and spoke with Raphael Brunner to get samples of the Hummel Panel Mount and 90 degree plug connector. The connectors are nickel plated brass and very durable, and attractive to our application.
Since we have been using the Hummel connectors we have no customer complaints or repair requests for damaged connectors.
Thank you Sealcon!!
Donna Bendickson Frank Camacho
Marketing/Purchasing Engineering
