METAL PRO CONDUIT SERIES Metal-Fitting Pro RoHS

Also available in PG
CONDUITS - Compatible Fittings On Page 13 F₁ F TL MATERIAL NICKEL PLATED BRASS

A PROTECTION CATEGORY IP 67
Metal-Conduit Pro A (Smooth PVC Coated) D d Thread Type Hole for Non-Threaded
Suggested Clearance
Mounting OPERATING TEMPERATURE -4°F - 176°F (-20°C - 80°C)
L
Inside Outside Thread Body Clearance Fits to DN Size
Diameter (d) Diameter (D) Length (TL) Length (L) Wrench (F₁) Wrench (F) Hole (A) Meleon Pro
Thread Size in (mm) in (mm) in (mm) in (mm) in (mm) in (mm) +.01” (.25 mm) A / B / C Part Numbers
M12 X 1.5 .65 (16.5) .96 (24.5) .39 (10) 1.22 (31) .79 (20) .87 (22) .47 (12) - / 9 / 9 MPM1209-BR
M16 X 1.5 .75 (19) 1.15 (29.2) .39 (10) 1.38 (35) .94 (24) 1.02 (26) .63 (16) 10 / 11 / 11 MPM1611-BR
M16 X 1.5 .87 (22) 1.28 (32.6) .45 (11.5) 1.54 (39) 1.06 (27) 1.14 (29) .63 (16) 12 / 13 / 13 MPM1612-BR
Part Numbers M20 X 1.5 .87 (22) 1.28 (32.6) .51 (13) 1.52 (38.7) 1.06 (27) 1.14 (29) .79 (20) 16 / 16 / 16 MPM2016-BR
MP-1016-SPA M25 X 1.5 1.08 (27.5) 1.53 (38.8) .59 (15) 1.61 (41) 1.30 (33) 1.38 (35) .98 (25) 21 / 21 / 21 MPM2521-BR
MP-1218-SPA M32 X 1.5 1.36 (34.5) 1.97 (50) .59 (15) 1.93 (49) 1.70 (43) 1.77 (45) 1.26 (32) 27 / 26 / 26 MPM3226-BR
MP-1621-SPA M40 X 1.5 1.71 (43.5) 2.36 (60) .63 (16) 2.01 (51) 2.05 (52) 2.13 (54) 1.57 (40) 35 / 35 / 35 MPM4035-BR
MP-2127-SPA M50 X 1.5 1.95 (49.5) 2.73 (69.3) .71 (18) 2.40 (61) 2.36 (60) 2.48 (63) 1.97 (50) 40 / 40 / 40 MPM5040-BR
MP-2733-SPA M63 X 1.5 2.44 (62) 3.35 (85) .79 (20) 2.87 (73) 2.91 (74) 3.03 (77) 2.48 (63) 51 / 51 / 51 MPM6351-BR
MP-3542-SPA
MP-4048-SPA 1/4” NPT .65 (16.5) .96 (24.5) .39 (10) 1.22 (31) .79 (20) .87 (22) .49 (12.5) 10 / 11 / 11 MPN1410-BR
1.38 (35)
.79 (20)
.87 (22)
MP-5160-SPA 3/8” NPT .75 (19) 1.15 (29.2) .45 (11.5) 1.52 (38.7) 1.06 (27) 1.14 (29) .68 (17.2) 12 / 13 / 13 MPN3812-BR
MPN1216-BR
.83 (21.1)
16 / 16 / 16
1.28 (32.6)
.51 (13)
.87 (22)
Metal-Conduit Pro B (With Braid) 1/2” NPT 1.08 (27.5) 1.53 (38.8) .59 (15) 1.61 (41) 1.30 (33) 1.38 (35) 1.05 (26.7) 21 / 21 / 21 MPN3421-BR
3/4” NPT
1” NPT 1.36 (34.5) 1.97 (50) .59 (15) 1.93 (49) 1.70 (43) 1.77 (45) 1.35 (34.3) 27 / 26 / 26 MPN1026-BR
1-1/4” NPT 1.71 (43.5) 2.36 (60) .63 (16) 2.01 (51) 2.05 (52) 2.13 (54) 1.7 (43.2) 35 / 35 / 35 MPN5435-BR
1-1/2” NPT 1.95 (49.5) 2.73 (69.3) .71 (18) 2.40 (61) 2.36 (60) 2.48 (63) 1.9 (48.3) 40 / 40 / 40 MPN6440-BR
2” NPT 2.44 (62) 3.35 (85) .79 (20) 2.87 (73) 2.91 (74) 3.03 (77) 2.4 (61) 51 / 51 / 51 MPN2051-BR
Metal-Fitting Pro S Also available in PG RoHS

Part Numbers F₁ F TL MATERIAL NICKEL PLATED BRASS
MP-0914-SPB A
MP-1116-SPB D d Thread Type PROTECTION CATEGORY IP 54
MP-1318-SPB Suggested Clearance
MP-1621-SPB Hole for Non-Threaded OPERATING TEMPERATURE -4°F - 176°F (-20°C - 80°C)
Mounting
MP-2126-SPB L
MP-2632-SPB Inside Outside Thread Body Clearance Fits to DN SIze
MP-3541-SPB Diameter (d) Diameter (D) Length (TL) Length (L) Wrench (F₁) Wrench (F) Hole (A) Meleon Pro
MP-4046-SPB Thread Size in (mm) in (mm) in (mm) in (mm) in (mm) in (mm) +.01” (.25 mm) A / B / C Part Numbers
MP-5157-SPB M12 X 1.5 .65 (16.5) .96 (24.5) .39 (10) 1.34 (34) .79 (20) .87 (22) .47 (12) - / 9 / 9 MPSM1209-BR
M16 X 1.5 .75 (19) 1.15 (29.2) .39 (10) 1.38 (35) .79 (20) .87 (22) .63 (16) 10 / 11 / 11 MPSM1611-BR
Metal-Conduit Pro C (PVC Coated With Braid) M16 X 1.5 .87 (22) 1.28 (32.6) .45 (11.5) 1.46 (37) .94 (24) 1.02 (26) .63 (16) 12 / 13 / 13 MPSM1612-BR
M20 X 1.5 .87 (22) 1.28 (32.6) .51 (13) 1.61 (41) 1.06 (27) 1.14 (29) .79 (20) 16 / 16 / 16 MPSM2016-BR
M25 X 1.5 1.08 (27.5) 1.53 (38.8) .59 (15) 1.73 (44) 1.30 (33) 1.38 (35) .98 (25) 21 / 21 / 21 MPSM2521-BR
M32 X 1.5 1.36 (34.5) 1.97 (50) .59 (15) 2.01 (51) 1.70 (43) 1.77 (45) 1.26 (32) 27 / 26 / 26 MPSM3226-BR
M40 X 1.5 1.71 (43.5) 2.36 (60) .63 (16) 2.13 (54) 2.05 (52) 2.13 (54) 1.57 (40) 35 / 35 / 35 MPSM4035-BR
M50 X 1.5 1.95 (49.5) 2.73 (69.3) .71 (18) 2.52 (64) 2.36 (60) 2.48 (63) 1.97 (50) 40 / 40 / 40 MPSM5040-BR
M63 X 1.5 2.44 (62) 3.35 (85) .79 (20) 2.99 (76) 2.91 (74) 3.03 (77) 2.48 (63) 51 / 51 / 51 MPSM6351-BR
1/4” NPT .65 (16.5) .96 (24.5) .39 (10) 1.38 (35) .79 (20) .87 (22) .49 (12.5) 10 / 11 / 11 MPSN1410-BR
Part Numbers 3/8” NPT .75 (19) 1.15 (29.2) .45 (11.5) 1.46 (37) .79 (20) .87 (22) .68 (17.2) 12 / 13 / 13 MPSN3812-BR
MP-0915-SPC 1/2” NPT .87 (22) 1.28 (32.6) .51 (13) 1.61 (41) 1.06 (27) 1.14 (29) .83 (21.1) 16 / 16 / 16 MPSN1216-BR
MP-1117-SPC 3/4” NPT 1.08 (27.5) 1.53 (38.8) .59 (15) 1.73 (44) 1.30 (33) 1.38 (35) 1.05 (26.7) 21 / 21 / 21 MPSN3421-BR
MP-1319-SPC 1” NPT 1.36 (34.5) 1.97 (50) .59 (15) 2.01 (51) 1.70 (43) 1.77 (45) 1.35 (34.3) 27 / 26 / 26 MPSN1026-BR
MP-1622-SPC 1-1/4” NPT 1.71 (43.5) 2.36 (60) .63 (16) 2.13 (54) 2.05 (52) 2.13 (54) 1.7 (43.2) 35 / 35 / 35 MPSN5435-BR
MP-2127-SPC 1-1/2” NPT 1.95 (49.5) 2.73 (69.3) .71 (18) 2.52 (64) 2.36 (60) 2.48 (63) 1.9 (48.3) 40 / 40 / 40 MPSN6440-BR
MP-2633-SPC 2” NPT 2.44 (62) 3.35 (85) .79 (20) 2.99 (76) 2.91 (74) 3.03 (77) 2.4 (61) 51 / 51 / 51 MPSN2051-BR
MP-3542-SPC
MP-4047-SPC
MP-5158-SPC
13
Dimensions and specifications may be changed without prior notice
