P. 9
www.SealconUSA.com
1-800-456-9012 / 303-699-1135
Nylon-Fitting Y Bulkhead Fitting WITH Thread
Conduit Fittings Thread Directly Into Bulkhead Fitting
MATERIAL NYLON - POLYAMIDE
Flange Type 1: Flange Type 2:
PG 11 - PG 21 PG 29 - PG 48 OPERATING TEMP.
G H G H -58°F - 248°F
E (-50°C - 120°C)
L L COLORS BLACK (RAL 9005)
Part Numbers W W E
PG 11 - PG 21 PG 29 - PG 48
Flange 1 Flange 2
Distance Between
Thead Type Length (L) Width (W) Height (H) Holes (G) Hole Diameter (E)
& Size Flange in (mm) in (mm) in (mm) in (mm) in (mm) Part Numbers
PG11 1 1.93 (49) 1.85 (47) 1.38 (35) 1.46 (37) .17 (4.3) FL-11-BK
PG16 1 1.93 (49) 1.85 (47) 1.38 (35) 1.46 (37) .17 (4.3) FL-16-BK
PG21 1 2.72 (69) 2.56 (65) 1.73 (44) 2.03 (51.6) .24 (6.0) FL-21-BK
PG29 2 3.54 (90) 3.07 (78) 2.17 (55) 2.54 (64.5) .26 (6.5) FL-29-BK
Nylon-Fitting T PG36 2 3.9 (99) 3.7 (94) 2.6 (66) 3.11 (79.5) .26 (6.5) FL-36-BK
PG48 2 4.57 (116) 3.98 (101) 2.99 (76) 3.44 (87.5) .26 (6.5) FL-48-BK
Nylon-Fitting Clip
MATERIAL NYLON - POLYAMIDE
H OPERATING TEMPERATURE -22°F - 176°F (-30°C - 80°C)
C
E COLORS BLACK (RAL 9005)
Part Numbers L J
PFT10 Screw Head Screw Hole Body Body Height to
PFT12 Size (J) Size (E) Length (L) Height (H) Center (C) Fits to
PFT17 Thread (AG) in (mm) in (mm) in (mm) in (mm) in (mm) Poleon DN Part Numbers
PFT23 DN10 .20 (5) .28 (7) 1.13 (28.7) .62 (15.7) 1.08 (27.5) 10 PFC10
PFT29 DN12 .21 (5.3) .33 (8.3) 1.17 (29.8) .52 (13.1) .94 (24) 12 PFC12
DN14 .21 (5.3) .34 (8.5) 1.39 (35.2) .70 (17.75) 1.15 (29.3) 14 PFC14
DN17 .21 (5.3) .34 (8.5) 1.58 (40.2) .78 (19.75) 1.31 (33.2) 17 PFC17
Bulkhead Fitting WITHOUT Thread DN23 .21 (5.3) .34 (8.7) 2.07 (52.6) .93 (23.5) 1.59 (40.5) 23 PFC23
29
1.89 (48)
2.39 (60.7)
1.16 (27)
.43 (11)
DN29
PFC29
.25 (6.5)
Conduit Clamps Directly Into Bulkhead Fitting DN37 .25 (6.5) .43 (11) 2.72 (69) 1.06 (30.4) 2.24 (57) 37 PFC37
DN50 .25 (6.5) .43 (11) 3.43 (87) 1.49 (37.9) 2.80 (71) 50 PFC50
Additional fittings that are compatible with the
Nylon Conduit Series
Elbow Fitting See page 15 for more information
TURN TO SEAL MATERIAL NYLON - POLYAMIDE
PROTECTION CATEGORY IP 65
OPERATING TEMPERATURE -40°F - 230°F (-40°C - 110°C)
Part Numbers
FT-11-BK
FT-16-BK
FT-21-BK Straight Fitting See page 14 for more information
FT-29-BK TURN TO SEAL MATERIAL NYLON - POLYAMIDE
FT-36-BK
FT-48-BK PROTECTION CATEGORY IP 65
OPERATING TEMPERATURE -40°F - 230°F (-40°C - 110°C)
9
Dimensions and specifications may be changed without prior notice
