Hensel ENYCASE Thermoplastic Cable Junction Box 16-35 mm | FK ENYCASE Fire Resistance | FK6505

Sealcon #: FK6505
Size: FK ENYCASE Fire Resistance
Material: FK 276 x 515 x 138 mm
Hensel #: FK 6505
Cover screws and mounting screws included.

Cable junction box E90 16-35 mm², Cu, “r”
Connection box E90 16-50 mm², Cu, “r”
5-pole per pole 6 x 16 mm² r, 4 x 25 mm² r, 4 x 35 mm² r, 2 x 50 mm² r
Connecting terminal made from ceramic with resistance to high temperatures
Mounted cable entries 2 ASS 63,
Sealing range Ø 20-48 mm
On the longitudinal sides each with 2 locking screws M 50
Intrinsic fire resistance in accordance with DIN 4102-12 (German standard) in combination with function-retaining cables
Tested with cable manufacturers Dätwyler, Prysmian and Eupen for the intrinsic fire resistance E90, see test certificate no.: P-1011 DMT DO,
Mounted using exterior wall fixings
Keyhole 8 mm (dowel refer to technical data)
For normal environment and protected outdoor

Need Technical Assistance?
Give our technical sales team a call
(303) 699-1135 | (800) 456-9012
Catalog Page
  • Rated insulation voltage Ui = 690 V a.c./d.c.
    Rated current: 150 A
    Material External brackets for wall fixing: Stainless steel 1.4462, resistance class IV
    Enclosure including lid: electrolytically galvanized steel sheet, outer screws: Stainless steel 1.4571, resistance class III
    Tightening torque for terminal 2.5 Nm
    Degree of protection IP 65 (ASS)
    Height 276 mm
    Width 515 mm
    Depth 138 mm
    Weight 12,7 kg
    In accordance with DIN 4102 part 12
    IK10 (20 Joule)
