303 Stainless Steel Standard | PVDF PG Strain Relief | Cord Grips
The top three benefits to a 303 stainless steel standard | PVDF | Strain Relief Connectors / Cable Gland / Cord Grip are first and foremost the ability to use the fitting in high performance applications, second the corrosion resistance, and third the resistance to extreme temperatures both high and low.
| Standard Fittings | PVDF Fittings | ||
 |
 |
||
| Part Numbers | Cable Range | Thread Type | |
|---|---|---|---|
| Stainless Steel | Stainless Steel | Inches (mm) | |
| CD07AA-SS | CD07AA-SV | .12" - .26" (3 - 6.5 mm) | PG 7 |
| CD07AR-SS | CD07AR-SV | .08" - .20" (2 - 5 mm) | PG 7 |
| CD09AA-SS | CD09AA-SV | .16" - .31" (4 - 8 mm) | PG 9 |
| CD09AR-SS | CD09AR-SV | .08" - .24" (2 - 6 mm) | PG 9 |
| CD11AA-SS | CD11AA-SV | .20" - .39" (5 - 10 mm) | PG 11 |
| CD11AR-SS | CD11AR-SV | .12" - .28" (3 - 7 mm) | PG 11 |
| CD13AA-SS | CD13AA-SV | .24" - .47" (6 - 12 mm) | PG 13 / 13.5 |
| CD13AR-SS | CD13AR-SV | .20" - .35" (5 - 9 mm) | PG 13 / 13.5 |
| CD16AA-SS | CD16AA-SV | .39" - .55" (10 - 14 mm) | PG 16 |
| CD16AR-SS | CD16AR-SV | .28" - .47" (7 - 12 mm) | PG 16 |
| CD21AA-SS | CD21AA-SV | .51" - .71" (13 - 18 mm) | PG 21 |
| CD21AR-SS | CD21AR-SV | .35" - .63" (9 - 16 mm) | PG 21 |
| CD29AA-SS | CD29AA-SV | .71" - .98" (18 - 25 mm) | PG 29 |
| CD29AR-SS | CD29AR-SV | .51" - .79" (13 - 20 mm) | PG 29 |
| CD36AA-SS | CD36AA-SV | .87" - 1.26" (22 - 32 mm) | PG 36 |
| CD36AR-SS | CD36AR-SV | .79" - 1.02" (20 - 26 mm) | PG 36 |
