Hensel ENYCASE Thermoplastic Cable Junction Box | FK ENYCASE Fire Resistance | FK5000

Sealcon #: FK5000
Size: FK ENYCASE Fire Resistance
Material: FK 255 x 255 x 160 mm
Hensel #: FK 5000
Cover screws and mounting screws included.

Communication junction box E30
For the installation of connecting device for telecommunications
Without terminals
With mounting brackets for mounting a maximum of 2 connecting devices for telecommunications
Intrinsic fire resistance in accordance with DIN 4102-12 (German standard) in combination with function-retaining cables
Cable entry via integrated elastic membranes
Cable entry on 4 sides each 1 x up to Ø 36 mm and 4 x up to Ø 14 mm
The attached screw anchors must be used for
Concrete ≥ C20/25, B25 up to ≤ C50/60, B55
The use of this equipment requires the approval from the building and regulatory authorities for the individual case
General approval by the German building authorities DIBt: Z-86.1-37, Celsion fire protection systems

Need Technical Assistance?
Give our technical sales team a call
(303) 699-1135 | (800) 456-9012
Catalog Page
  • Material Sheet steel, powder-coated
    Degree of protection IP 55
    Height 255 mm
    Width 255 mm
    Depth 160 mm
    Weight 5,97 kg
    In accordance with intrinsic fire resistance E 30 in accordance with DIN 4102 part 12
    IK10 (20 Joule)
